Click CMA651 Mode White Moulded DP Switched Fused Connection Unit 13A
CMA651
Click CMA651 Mode 13A Switched Fused Connection Unit – Double Pole Safety for Fixed Appliance Installations
The Click CMA651 is a 13A switched fused connection unit with double pole switching, designed to provide safe, controlled power to fixed appliances. With a clean white moulded finish and part of the Click Mode range, it’s ideal for domestic or commercial installations requiring clear isolation and overload protection.
- 13A Rating with Fuse: Integrated fuse offers protection for fixed loads such as boilers, fans, or hand dryers.
- Double Pole Switching: Isolates both live and neutral conductors for added safety during maintenance.
- Integrated Switch: Allows convenient control and isolation of connected appliances.
- Mode Range Styling: Matches other Click Mode accessories for a uniform, professional finish.
- Flush Mounted Design: Installs neatly into standard back boxes for a clean, low-profile look.
Technical Specification
- Current Rating: 13A
- Switch Type: Double Pole
- Type: Switched Fused Connection Unit
- Finish: White moulded
- Mounting: Flush
✅ Install the Click CMA651 for reliable fused switching with full isolation and a clean, professional finish!
(Note- We have introduced an internal stock identification code, using 'EExxx' references. Rest assured you will be supplied the genuine manufacturer items)
| Ean Code | 5055112822182 |
| Range | Click Mode |
| Includes 13a Switch Socket? | N |
| Product | Connection Unit - Spur |
| Type | Switched |
| Telephone Master | N |
| Includes Rcd? | N |
| Screwless? | N |
| Telephone Secondary | N |
| Tv Socket | N |
| Ingress Protection | IP20 |
| Fm/dab | N |
| Satellite | N |
| Rj11 | N |
| Rj45 Cat 5e | N |
| Rj45 Cat 6 | N |
| Length | 86 mm |
| USB Included | N |
| Fixing Centres | 60.3 mm |
| Mounting Box Minimum Depth | 25 mm |
| Number Of Gangs | 1 |
| Voltage | 250 V |
| Warranty | 20 Years |
| Pole Configuration | Double Pole (2P) |
| Width | 86 mm |
| Depth | 9.5 mm |
| Current Rating | 13 A |
| Standards | BS 1363-4 BS 1362 |
| Qualifier | FCU Plate |
| Ce Approved | N |
| Height | 86 mm |
| Body Material | Urea |
| Gangs | 1 Gang |
| Neon Indicator | N |
| Face Colour | Polar White |
| Rocker Colour | White |
| Flex Outlet | N |
| Legend | Fused |
| Switched/unswitched | Switched |
| Fuse Fitted | Y |
| Lockable? | N |
