Eaton MEM EAMS100ME Memshield3 2 Module DP RCD 100A 100mA
EAMS100ME
Memshield3 2-Module Double Pole 100A 100mA Type A RCCB – Incoming Device for SPN Distribution Boards
The Eaton Memshield3 100A 100mA Double Pole RCCB provides essential earth fault protection for single-phase Type A distribution boards. Designed as a separate incoming device, it ensures enhanced electrical safety by detecting residual current leakage, reducing the risk of electric shock and fire hazards.
- Reliable Earth Fault Protection: Provides 100mA residual current protection for enhanced safety.
- 100A Rated Capacity: Suitable for high-power single-phase distribution boards.
- Double Pole Design: Ensures full isolation and protection for the entire board.
- Type A RCCB: Detects both AC and pulsating DC residual currents for comprehensive safety.
- Separate Incoming Device: Supplied separately for flexible installation within SPN distribution boards.
Technical Specification
- Device Type: RCCB (Residual Current Circuit Breaker)
- Number of Poles: Double Pole (DP)
- Rated Current: 100A
- Residual Current Sensitivity: 100mA
- RCCB Trip Type: Type A (detects AC and pulsating DC leakage currents)
- Mounting Type: DIN Rail
- Application: SPN Type A Distribution Boards
✅ Choose the Eaton Memshield3 100A 100mA Double Pole RCCB for reliable earth fault protection in single-phase distribution boards.
(Note- We have introduced an internal stock identification code, using 'EExxx' references. Rest assured you will be supplied the genuine manufacturer items)
| Ean Code | 5019586158185 |
| Range | Eaton Memshield3 |
| Trip Type | Type A |
| Short Circuit Rating | 10 kA |
| Cable Capacity | 1.5 to 35 mm2 |
| Sensitivity | 100 mA |
| Product | Incomers & Isolators |
| Type | RCCB |
| Ingress Protection | IP20 |
| Voltage | 230|400 V |
| Pole Configuration | Double Pole (2P) |
| Mounting | DIN Rail |
| Width | 35 mm |
| Current Rating | 100A |
| Standards | IEC/EN 61008 |
| Rcd Sensitivity | 100 mA |
| Number Of Poles | Double Pole (2P) |
| Height | 80 mm |
| Number Of Modules | 2 |
