BG Electrical CUCRB10DPA-01 Bidirectional 10A B Curve Compact RCBO 30mA Type A 2 Pole Single Module
CUCRB10DPA-01
BG Electrical 10A Bidirectional Compact RCBO – Type A, 30mA, 2 Pole, Single Module for BG Consumer Units
The BG Electrical 10A Bidirectional Compact RCBO delivers combined residual current and circuit protection in a compact single-module format. Designed for use with BG consumer units and enclosures, it features bidirectional functionality, a 2-pole design, and Type A RCD protection—ideal for lighting and small load applications.
- 10A B Curve Protection: Provides precise overload and short-circuit protection for lighting and low-power circuits.
- Bidirectional Operation: Safe performance regardless of line/load orientation for simplified installation.
- Compact 2-Pole Design: Single-module layout saves space and integrates cleanly with BG boards and enclosures.
- Durable & Reliable: Operates from -25°C to +40°C with a 6kA breaking capacity for consistent protection in varying environments.
- Installer Ready: Manual test button and integrated blue neutral lead included for quick, compliant setup.
Technical Specification
- Rating: 10A
- Trip Curve: B curve
- RCD Type: Type A
- Tripping Sensitivity: 30mA
- Breaking Capacity: 6kA
✅ Choose the BG 10A Bidirectional Compact RCBO for efficient, safe, and space-saving protection across lighting and small circuit installations!
| Trip Type | B Curve Type A |
| Product | RCBO |
| Type | Singe Pole + N |
| Current Rating | 10A |
