Timeguard LEDX10FLBN Night Eye Black Wide Beam LED Floodlight With Instant ON Light & Adjustable Quick Fit Bracket IP55 10W 1000 Lumens
LEDX10FLBN
Timeguard LEDX10FLBN Night Eye 10W Wide Beam LED Floodlight – Black, Quick Fit Bracket, 1000lm Output, IP55 Rated
The Timeguard LEDX10FLBN Night Eye is a rugged 10W LED floodlight built for harsh environments and coastal installations. With a wide beam output, stainless steel fixings, and advanced motion sensing, this unit is ideal for secure, long-lasting outdoor lighting solutions.
- Powerful & Efficient Output: 10W LED delivers 1000 lumens of 4000K cool white light with instant-on functionality.
- Built for Harsh Conditions: Marine-grade aluminium heat sink, polycarbonate body, and 316 stainless steel bracket for rust resistance.
- Wide PIR Coverage: Integrated 180° sensor with 12m range and adjustable ON time from 5 seconds to 10 minutes.
- Parallel Switching & Slave Output: Link up to 4 LEDXPIRN units or control additional lighting loads via the slave terminal.
- Quick & Easy Installation: Pre-fitted quick fit bracket ensures fast, secure mounting for professional applications.
Technical Specification
- Operating Voltage: 230V AC
- Maximum Load: 10W LED
- Lumens Output: 1000lm
- Colour Temperature: 4000K (Cool White)
- IP Rating: IP55
✅ Install the Timeguard LEDX10FLBN for robust, energy-efficient lighting with built-in PIR detection and marine-grade durability!
(Note- We have introduced an internal stock identification code, using 'EExxx' references. Rest assured you will be supplied the genuine manufacturer items)
| Range | Timeguard Night Eye |
| Product | LED Floodlight |
| Photocell Included | N |
| Type | Floodlight |
| Microwave Sensor Included | N |
| Lamp Type | LED Fixed |
| Self-contained | N |
| Wattage | 10 W |
| Ingress Protection | IP55 |
| Colour | Black |
| Beam Angle | 110 Degrees |
| Colour Temperature | 4000 K |
| Light Output | 1000 Lm |
| Voltage | 230 V |
| Energy Efficiency Class | E |
| Warranty | 3 Years |
| Unit Weight | 0.418 kg |
| Width | 124 mm |
| Depth | 97 mm |
| Ce Approved | Y |
| Mounting Type | Surface |
| Height | 117 mm |
| Mounting Position | Surface |
| Fire Rated | N |
| Pir Included | N |
| Cover Included | Y |
| Led Driver Included? | Y |
| Emergency | N |
| Housing Material | Polycarbonate/Stainless Steel |
| Face Shape | Rectangular |
| Corrosion Resistant | N |
| Adjustability | Adjustable |
| Vandal Resistant | N |
| Ballast/starter Included | N |
| Lamp(s) Included? | Y |
| Housing Colour | Black |
