Lawson TIA32M63 Type TIA BS88, IEC60269-2 Industrial HRC Motor Rated Fuse Link With Offset Bolted Tags 32M63 Amps 415V ac

Lawson TIA32M63 Type TIA BS88 Motor Rated HRC Industrial Fuse Link – 32M63A, Offset Bolted Tags, High Inrush Motor Protection

The Lawson TIA32M63 Type TIA HRC Fuse Link is specifically designed for motor circuits requiring high inrush tolerance. With offset bolted tags and compliance to BS88 and IEC60269-2 standards, it offers robust and safe protection for motors and related equipment in industrial settings.

• Motor Rated 32M63A: Provides enhanced protection for motors with high start-up currents and variable loads.
• Offset Bolted Tag Design: Compatible with compact panels and non-standard BS88 fuse holders.
• High Fault Capacity: Withstands fault currents up to 80kA AC and 40kA DC for safe disconnection.
• Dual Voltage Application: Operates at 415V AC (tested to 457V) and 250V DC for versatility across installations.
• gG Classification: Fully compliant with BS88: Part 2 and UK Wiring Regulations for industrial motor protection.

Technical Specification

• Current Rating: 32M63A
• Voltage Rating: 415V AC / 250V DC
• Breaking Capacity: 80kA AC / 40kA DC
• Standards: BS88: Part 2, IEC60269-2
• BS Reference Code: A2

✅ Use the Lawson TIA32M63 Fuse Link for safe, reliable motor protection in demanding industrial environments!

(Note- We have introduced an internal stock identification code, using 'EExxx' references. Rest assured you will be supplied the genuine manufacturer items)
