Lawson TIA25 Type TIA BS88, IEC60269-2 Industrial HRC Fuse Link With Offset Bolted Tags 25 Amps 415V ac

Lawson TIA25 Type TIA BS88 HRC Industrial Fuse Link – 25A, Offset Bolted Tags, Compact Protection for Industrial Applications

The Lawson TIA25 Type TIA HRC Fuse Link offers reliable circuit protection for medium-load industrial systems. Featuring offset bolted tags and certified to BS88 and IEC60269-2 standards, it's ideal for control panels, machinery circuits, and non-standard installations.

• 25A Current Rating: Suitable for protecting control equipment, lighting circuits, and auxiliary loads.
• Offset Bolted Tag Format: Compatible with compact or specialist fuse holders and enclosures.
• High Breaking Capacity: Certified for 80kA AC and 40kA DC to manage high fault conditions.
• Dual Voltage Rated: Operates at 415V AC (tested to 457V) and 250V DC for broad application use.
• gG Classification: Fully compliant with BS88: Part 2 and the latest UK Wiring Regulations.

Technical Specification

• Current Rating: 25A
• Voltage Rating: 415V AC / 250V DC
• Breaking Capacity: 80kA AC / 40kA DC
• Standards: BS88: Part 2, IEC60269-2
• BS Reference Code: A2

✅ Depend on the Lawson TIA25 Fuse Link for compact, regulation-compliant protection in medium-load industrial systems!

(Note- We have introduced an internal stock identification code, using 'EExxx' references. Rest assured you will be supplied the genuine manufacturer items)
