Lawson TIA16 Type TIA BS88, IEC60269-2 Industrial HRC Fuse Link With Offset Bolted Tags 16 Amps 415V ac
TIA16
Lawson TIA16 Type TIA BS88 HRC Industrial Fuse Link – 16A, Offset Bolted Tags, Compact Protection for Control & Auxiliary Circuits
The Lawson TIA16 Type TIA HRC Fuse Link delivers precise, compact circuit protection for industrial and control applications. With offset bolted tags and full compliance to BS88 and IEC60269-2, it's ideal for use in specialist distribution panels and fusegear.
- 16A Rated Protection: Suitable for low-current industrial loads and auxiliary control circuits.
- Offset Bolted Tags: Designed for compact or non-standard installations requiring tag offset alignment.
- High Breaking Capacity: Safely handles fault conditions up to 80kA AC and 40kA DC.
- Motor Rated & Dual Voltage: Operates at 415V AC (tested to 457V) and 250V DC.
- BS88 gG Compliant: Meets the latest UK Wiring Regulations for general-purpose industrial protection.
Technical Specification
- Current Rating: 16A
- Voltage Rating: 415V AC / 250V DC
- Breaking Capacity: 80kA AC / 40kA DC
- Standards: BS88: Part 2, IEC60269-2
- BS Reference Code: A2
✅ Rely on the Lawson TIA16 Fuse Link for compact, regulation-compliant protection in control and auxiliary power systems!
(Note- We have introduced an internal stock identification code, using 'EExxx' references. Rest assured you will be supplied the genuine manufacturer items)
| Breaking Capacity | 80000 Amperes |
| Rated Voltage | 415 V |
| Ean Code | 5036159000214 |
| Connection Type | Bolted Tag |
| Product | Fuse |
| Type | N&T |
| Length | 86 mm |
| Voltage | 415 V |
| Width | 22 mm |
| Current Rating | 16A |
| Standards | BS 88 IEC 60269-2 EN 60269-2 |
| Qualifier | gG |
| Rated Current | 16 A |
