Lawson TCP6 Type TCP BS88, IEC60269-2 Industrial HRC Fuse Link With Offset Bolted Tags 6 Amps 415V ac
TCP6
Lawson TCP6 Type TCP BS88 HRC Industrial Fuse Link – 6A, Offset Bolted Tags, Compact Circuit Protection
The Lawson TCP6 Type TCP HRC Fuse Link offers reliable protection for low-current circuits in industrial installations. Designed to BS88 and IEC60269-2 standards, it features offset bolted tags for use in non-standard fuse holders and compact control panels.
- Low Current Rated: 6A rating ideal for control circuits and sensitive equipment protection.
- Offset Bolted Tags: Provides compatibility with specialised distribution and panel systems.
- High Fault Capacity: Tested to 80kA AC and 40kA DC for dependable short-circuit performance.
- Motor Rated & AC/DC Compatible: Suitable for use in 415V AC motor circuits and 250V DC systems.
- gG Compliant: Fully meets BS88: Part 2 and UK Wiring Regulations requirements.
Technical Specification
- Current Rating: 6A
- Voltage Rating: 415V AC / 250V DC
- Breaking Capacity: 80kA AC / 40kA DC
- Standards: BS88: Part 2, IEC60269-2
- BS Reference Code: A4
✅ Install the Lawson TCP6 for precise, regulation-compliant protection in low-current industrial systems!
(Note- We have introduced an internal stock identification code, using 'EExxx' references. Rest assured you will be supplied the genuine manufacturer items)
| Breaking Capacity | 80000 Amperes |
| Rated Voltage | 415 V |
| Ean Code | 5036159000313 |
| Size | A4 |
| Connection Type | Offset Bolted Tag |
| Product | Fuse |
| Type | HRC |
| Length | 110 mm |
| Voltage | 415 V |
| Material | Ceramic |
| Width | 25 mm |
| Current Rating | 6A |
| Standards | BS88-2 |
| Rated Current | 6 A |
