Lawson TCP100M125 Type TCP BS88, IEC60269-2 Industrial HRC Motor Rated Fuse Link With Offset Bolted Tags 100M125 Amps 415V ac

Lawson TCP100M125 Type TCP BS88 Motor Rated HRC Fuse Link – 100M125A, Offset Bolted Tags, Industrial Motor Protection

The Lawson TCP100M125 Type TCP Motor Rated Fuse Link is designed for reliable protection of industrial motor circuits. With offset bolted tags and compliance to BS88 and IEC60269-2 standards, it ensures safety, durability, and compatibility in specialist switchgear and distribution applications.

• Motor Rated Design: Optimised for the unique demands of motor circuit protection in industrial environments.
• Offset Bolted Tags: Compatible with non-standard distribution equipment and offset fuse holders.
• High Breaking Capacity: Tested to 80kA AC and 40kA DC for secure disconnection under fault conditions.
• Versatile Voltage Suitability: Rated for 415V AC motor circuits and 250V DC installations.
• gG Fuse Link Classification: Fully compliant with BS88: Part 2 and UK Wiring Regulations.

Technical Specification

• Current Rating: 100M125A
• Voltage Rating: 415V AC / 250V DC
• Breaking Capacity: 80kA AC / 40kA DC
• Standards: BS88: Part 2, IEC60269-2
• BS Reference Code: A4

✅ Choose the Lawson TCP100M125 for reliable, motor-rated protection in challenging industrial setups!

(Note- We have introduced an internal stock identification code, using 'EExxx' references. Rest assured you will be supplied the genuine manufacturer items)
