Lawson NS4 Type NS BS88, IEC60269-2 Compact Dimension Industrial CDS Fuse Link With Offset Blade Tags 4 Amps 415V ac

Lawson NS4 Type NS Compact Industrial CDS Fuse Link – BS88 & IEC60269-2 Compliant, 4A, 415V AC, Offset Blade Tags

The Lawson NS4 Type NS CDS Fuse Link offers reliable, compact protection for commercial and industrial electrical circuits. Designed to BS88: Part 6 and IEC60269-2 standards, this 4A fuse link features offset blade tags and a high breaking capacity, ideal for motor-rated and general purpose applications.

• Compact CDS Design: Space-saving fuse link suitable for single or three-phase commercial and industrial installations.
• Standards Compliant: Manufactured to BS88: Part 6 and IEC60269-2 for safe and consistent operation.
• High Breaking Capacity: Rated to 80kA at 415V AC and 40kA at 250V DC where applicable.
• Offset Blade Tags: Compatible with BS88 blade-type fuse holders and distribution fusegear for straightforward installation.
• Certified Voltage Performance: Tested at 110% recovery voltage, suitable for systems up to 457V AC.

Technical Specification

• Current Rating: 4A
• Voltage Rating: 415V AC
• Breaking Capacity: 80kA AC
• Standard Compliance: BS88: Part 6 / IEC60269-2
• BS88 Reference: F1

✅ Choose the Lawson NS4 CDS Fuse Link for compact, reliable protection in commercial and industrial electrical systems!

(Note- We have introduced an internal stock identification code, using 'EExxx' references. Rest assured you will be supplied the genuine manufacturer items)
