Lawson NS32M50 Type NS BS88, IEC60269-2 Compact Dimension Industrial CDS Motor Rated Fuse Link With Offset Blade Tags 32M50 Amps 415V ac

230/240 Volt and 400/415 Volt Compact Dimension Fuse-Links to BS88: Part 6, IEC60269-2

Compact Type“CDSâ€fuse-links are for use in single or three phase commercial and industrial installations and can be fitted into BS88 bladed type fuse-holders and distribution fusegear.
The Lawson CLIPFIT range has rated voltages of 240V a.c. or 415V a.c. and has been certified at a test recove ry voltage of at least 110%. These fuse-links there fo re are suitable for use on systems with voltages up to 264 or 457V a.c. The rated and test voltages also ensure that the range meets all the transitional voltage re q u i re m e nts specified within the harmonised nominal voltages of 230/400V a.c.
A complementary range of solid/neutral links is available to suit our fuse-link rang e.

Specification:
Current Rating (A): 2,4,6,10,16,20,25,32
BS88 Reference: F1
Voltage Rating (V): 415a.c.
Breaking Cpacity: (kA): 80kA-a.c.
BS Standard: BS88: Part 6
IEC Standard: 60269-2

Dimesions:

A: 34.5mm
B: 17.5mm
D: 58.5mm
E: 12.7mm
F: 0.8mm
N: 3.5mm
