Lawson NS32M50 Type NS BS88, IEC60269-2 Compact Dimension Industrial CDS Motor Rated Fuse Link With Offset Blade Tags 32M50 Amps 415V ac

Lawson NS32M50 Type NS Compact Motor Rated CDS Fuse Link – BS88 & IEC60269-2 Compliant, 32M50A, 415V AC, Offset Blade Tags

The Lawson NS32M50 Type NS Compact CDS Motor Rated Fuse Link is engineered for dependable motor circuit protection in commercial and industrial installations. Certified to BS88: Part 6 and IEC60269-2 standards, this fuse link features offset blade tags and a high breaking capacity, ensuring safe and efficient operation.

• Motor Rated Protection: Designed with gM characteristics for effective and economical motor circuit fusegear usage.
• Compact CDS Design: Space-saving fuse link suitable for single and three-phase industrial and commercial applications.
• Certified Compliance: Meets BS88: Part 6 and IEC60269-2 standards for reliable and safe performance.
• High Breaking Capacity: Rated for 80kA at 415V AC and 40kA at 250V DC where applicable.
• Offset Blade Tags: Compatible with BS88 blade-type fuse holders and distribution boards for easy installation.

Technical Specification

• Current Rating: 32M50A
• Voltage Rating: 415V AC
• Breaking Capacity: 80kA AC
• Standard Compliance: BS88: Part 6 / IEC60269-2
• BS88 Reference: F1

✅ Trust the Lawson NS32M50 Motor Rated Fuse Link for compact, high-capacity protection in motor applications!

(Note- We have introduced an internal stock identification code, using 'EExxx' references. Rest assured you will be supplied the genuine manufacturer items)
