Lawson NS20M32 Type NS BS88, IEC60269-2 Compact Dimension Industrial CDS Motor Rated Fuse Link With Offset Blade Tags 20M32 Amps 415V ac

Lawson NS20M32 Type NS Compact Motor Rated CDS Fuse Link – BS88 & IEC60269-2 Compliant, 20M32A, 415V AC, Offset Blade Tags

The Lawson NS20M32 Type NS Compact CDS Motor Rated Fuse Link offers reliable and compact protection tailored for motor circuits in commercial and industrial settings. Certified to BS88: Part 6 and IEC60269-2 standards, it features offset blade tags and high breaking capacity, ensuring safe operation and compatibility with standard fusegear.

• Motor Rated Protection: Designed with motor circuit characteristics to optimise fusegear size and cost.
• Compact CDS Format: Ideal for single or three-phase commercial and industrial systems requiring space-efficient solutions.
• Certified Standards Compliance: Manufactured to BS88: Part 6 and IEC60269-2 for safe and reliable performance.
• High Breaking Capacity: Rated for 80kA at 415V AC and 40kA at 250V DC where applicable.
• Offset Blade Tags: Compatible with BS88 blade-type fuse holders and distribution fusegear for easy installation.

Technical Specification

• Current Rating: 20M32A
• Voltage Rating: 415V AC
• Breaking Capacity: 80kA AC
• Standard Compliance: BS88: Part 6 / IEC60269-2
• BS88 Reference: F1

✅ Depend on the Lawson NS20M32 Motor Rated Fuse Link for compact, high-performance protection in motor applications!

(Note- We have introduced an internal stock identification code, using 'EExxx' references. Rest assured you will be supplied the genuine manufacturer items)
