Integral LED ILDLFR70D008 EvoFire Satin Nickel Pressed Steel Square Fixed Fire-Rated LED Downlight With Glass Lens IP65 GU10 240V Length: 85mm - Width: 85mm - Recess Depth: 40mm - Cut-Out: 70mm
ILDLFR70D008
Integral LED ILDLFR70D008 EvoFire Square Fire-Rated Downlight – Satin Nickel IP65 GU10, 85mm x 85mm
The ILDLFR70D008 EvoFire is a fixed, square fire-rated downlight finished in satin nickel. Designed for GU10 LED lamps, it combines robust steel construction with a fully open design that enhances airflow and prolongs lamp life by reducing heat buildup. Ideal for modern, high-spec installations where safety and appearance are equally important.
- Fire-Rated for 30/60/90 Minutes: Fully tested to BS476 Part 21 for ceiling integrity and building regulation compliance.
- Discrete Ultra-Thin Bezel: 1mm square profile for a clean, flush finish with high-quality powder-coated surface.
- Cooler Lamp Operation: Open fitting allows up to 10°C cooler running temperatures than can-style alternatives.
- IP65 Rated: Water and dust resistant, making it ideal for use in bathrooms, kitchens and wet zones.
- Fast Installation: Loop-in/loop-out terminal block and GU10 holder simplify wiring and setup.
Technical Specification
- Max Lamp Wattage: 50W
- Input Voltage: 220–240V AC
- Dimmable: Yes (lamp dependent)
- Lamp Base: GU10
- IP Rating: IP65
Dimensions
- Length: 85mm
- Width: 85mm
- Recess Depth: 40mm
- Cut-Out: 70mm
✅ Choose the EvoFire Square Downlight in Satin Nickel for stylish, fire-rated protection with easy installation and superior airflow design.
(Note- We have introduced an internal stock identification code, using 'EExxx' references. Rest assured you will be supplied the genuine manufacturer items)
| Downlight Type | MAINS VOLTAGE GU10 |
| Recess Depth | 40 mm |
| Ean Code | 5055788228653 |
| Range | Integral EVOFire |
| Product | LED Fire Rated Downlight |
| Photocell Included | N |
| Type | Downlight |
| Microwave Sensor Included | N |
| Lamp Type | GU10 |
| Self-contained | N |
| Lamp Base | GU10 |
| Dimmable | N |
| Ingress Protection | IP65 |
| Length | 85 mm |
| Voltage | 220-240 V |
| Warranty | 3 Years |
| Unit Weight | 0.07 kg |
| Width | 85 mm |
| Ce Approved | Y |
| Cut-out Diameter | 70 mm |
| Mounting Type | Recessed |
| Mounting Position | Ceiling |
| Fire Rated | Y |
| Pir Included | N |
| Cover Included | Y |
| Cover Type | Glass Cover |
| Led Driver Included? | N |
| Emergency | N |
| Housing Material | Steel |
| Cover Material | Glass |
| Cover Colour | Clear |
| Face Shape | Square |
| Corrosion Resistant | N |
| Bezel/trim Colour | Satin Nickel |
| Adjustability | Fixed |
| Vandal Resistant | N |
| Ballast/starter Included | N |
| Lamp(s) Included? | N |
| Number Of Lamps | 1 |
