Doncaster Cables EV-ULTRA3C6.0CAT5 EV-Ultra 3 Core 6mm² Power & Cat 5 Cable For Electric Vehicle Charging Points (Priced Per Mtr)

EV-Ultra 3 Core 6mm² Power & Cat 5 Cable – Integrated Power & Data for EV Charging

The EV-Ultra 3 Core 6mm² Power & Cat 5 Cable is specifically designed for the installation of electric vehicle charge points, combining power and data conductors within a single, double-sheathed cable for enhanced protection. Suitable for a variety of installation methods, including surface mounting, tray work, and direct burial with appropriate mechanical protection, this cable ensures a streamlined and efficient setup.

Manufactured by Doncaster Cables, the innovative EV Ultra cable range combines power and data connectivity within a single cable for efficient electric vehicle charging installations. Available in various conductor sizes and configurations, including steel wire armoured options, EV Ultra helps simplify cable routing and reduce installation time. Explore our selection of EV chargers and charging equipment or browse additional EV charging cables for your next installation.

• Power & Data Combined: Integrates power conductors with an enhanced Cat 5 screened data cable.
• Space-Saving Design: Reduces storage and handling requirements.
• Easy Installation: Simplifies routing through walls and buildings, saving time and effort.
• Neat & Efficient Setup: Ensures a cleaner, more professional-looking installation.
• Versatile Application: Suitable for installation in air, clipped to surfaces, on cable trays/ladders, embedded in concrete, or laid directly in the ground with proper protection.

Technical Specification

• Maximum Current Rating: 58A
• Voltage Drop: 7.9 mV/A/m
• Conductor: Plain Annealed Copper, Class 2 Stranded (BS EN 60228)
• Insulation: Thermosetting XLPE Type GP8 (BS 7655-1.3)
• Bedding: Compatible Polymeric Material (PVC)
• Sheathing: Tuff Heat Resisting PVC Compound (DCC05/DCC07)
• Energy Monitor Cable: Cat5e FTP-Foil Screened, 4 twisted pair

✅ Choose the EV-Ultra 3 Core 6mm² Cable for a streamlined, efficient, and professional EV charge point installation!

(Note- We have introduced an internal stock identification code, using 'EExxx' references. Rest assured you will be supplied the genuine manufacturer items)
