FuseBox EV40ABDZ EV Charger Consumer Unit With 40A Bi-Directional RCBO, 100A Main Switch & Type 2 Surge Protection Device
EV40ABDZ
FuseBox EV40ABDZ – 40A EV Charger Supply Unit with RCBO & SPD Protection
The FuseBox EV40ABDZ is a dedicated supply unit for EV charger installations, equipped with a 100 A main switch, 40 A bi-directional RCBO, and integrated Type 2 surge protection device. Designed to meet BS EN 61439-3 and 18th Edition Amendment 2 wiring regulations, it delivers safe, compliant, and durable performance for both residential and commercial EV charging setups.
- Enhanced Protection: Includes 100 A main isolator, 40 A Type A RCBO (double-pole 1P+N) and Type 2 SPD.
- Residual Current Safety: 30 mA sensitivity with B-curve tripping for reliable fault detection.
- Robust Enclosure: Constructed from 1 mm electro-galvanised steel with RAL 9001 white powder-coated finish.
- Installer-Friendly Design: Features removable DIN rail, captive screws, side knock-outs, and 16 mm² cable capacity.
- Standards Compliance: Internal IP2X rated, certified to BS EN 61439-3 and Amendment 2 EV wiring standards.
Technical Specification
- Main Switch: 100 A isolator
- RCBO: 40 A Type A bi-directional (1P+N), 30 mA, B-curve
- Surge Protection: Type 2 SPD (SPD1MT2)
- Enclosure: 1 mm electro-galvanised steel, RAL 9001 white, IP2X internal
- Dimensions: 261 × 152 × 93 mm (H × W × D)
✅ The FuseBox EV40ABDZ is the ideal choice for 40 A EV charger installations, offering reliable protection and straightforward installation!
| Body Finish | Powder Coated |
| Rated Voltage | 230 V |
| Surge Protection Included | Yes |
| Installation Type | Domestic |
| Surge Protector Type | Type 2 |
| Product | Consumer Unit w/Main Switch, RCBO + SPD |
| Type | EV Charging |
| Ingress Protection | IP2XC |
| Pole Configuration | Double Pole (2P) |
| Mounting | Surface |
| Standards | BS EN 61439-3 |
| High Integrity | No |
| Door/lid Type | Solid |
| Body Colour | Cream RAL 9001 |
| Number Of Phases | Single |
| Body Material | Steel |
| Current Rating (max) | 100 A |
| Outgoing Ways | 1 Way |
| Incomer Included | Y |
| Incomer Type | Switch Disconnector |
| Incomer Current Rating | 100 A |
| Metered | N |
| Split Load | N |
| Rcd S Included | N |
| Outgoing Devices Included | Y |
| 18th Edition Compliant | Y |
